65'' LG UHD IR-Type Touch Interactive Digital Board - 65TR3DJ-B
Features
- Brightness : 390 nit (w/o Glass, Typ.)
- Multi Touch Point : 20 Points (Max.)
- Interface : HDMI (3), RGB (1), Audio In (1), RS-232C In (1), RJ45 (1), USB 3.0 Type A (3), USB 2.0 Type A (3), Audio Out / Optical Output, Touch USB (2)
True Interactivity forBringing People Together
Multi Touch
The TR3DJ series can simultaneously use up to 20 points of multi touch. This function offers a lifelike board touch experience and makes collaboration much easier.
Enhanced Visibility with Low Parallax
With 1mm gap between the screen and tempered glass, which supports low parallax, The TR3DJ series can offer precise touch and excellent writing experience.
Dual Pen &Dual Colour
The stylus pen comes in two different colours and with two different tip sizes of 3mm and 8mm. The dual pens enable users to write or draw simultaneously.
Easy Writing Experience
The TR3DJ series allows you to write and annotate on sources, so your writing experience can be easy and satisfying.
Air Class
Air Class supports connecting up to 30 students and offers interactive meetings for mobile devices on the same network, providing a variety of tools such as voting, answering, and sharing project texts. Air Class is easily accessible from the TR3DJ's main toolbar.
Built-in OPS Slot
The TR3DJ series supports OPS* slots, allowing you to easily and conveniently mount an OPS* device at the back of the digital board without the hassle of connecting to an external desktop, offering you more expanded functions.* OPS : Open Pluggable Specification
ScreenShare Pro
ScreenShare Pro enables you to show up to six shared screens or a file on a screen in real-time, and it has enhanced usability by allowing users to share Chromecast and Apple device mirroring on the same network without any additional application.
Bluetooth Connectivity
TR3DJ supports Bluetooth wireless connections to various devices such as speaker, mouse, keyboard, etc. This is optimal for building a hybrid environment so that online and offline meetings and classes can proceed smoothly.
Web Browser
The TR3DJ series supports an embedded Android web browser, so you can search the web easily and quickly, without connecting to an external tablet or computer.
Toolbar
The Toolbar allows you to easily find and run the tool you need. The annotation feature works on virtually all file types, and you can highlight the section you wish to emphasize using the Spotlight function. The countdown and stopwatch features help you manage class time effectively.
Audio Experience
The TR3DJ series supports built-in speakers in both sides of the front bezel which deliver clear audio experience.
USB Block
USB Block Mode is a security measure that helps prevent data from being copied to unauthorized devices, which is essential for being used in spaces where security is critical.
Android System | |
---|---|
Bluetooth | Bluetooth 4.0 |
LAN | Gigabit LAN |
Wi-Fi | 802.11a/b/g/n/ac |
Internal Memory - RAM | 3GB |
Internal Memory - Storage | 32GB |
Mechanical Specification | |
Monitor Dimension(W x H x D) | 1489×897×87mm |
Packed Weight | 48.5Kg |
Weight(Head) | 38.75Kg |
Bezel Width | 18.9/18.9/18.9/45.7mm |
Bezel Colour | Black |
Connectivity(Jack Interface) | |
Output - Touch USB | Yes(2) |
Output - Audio Out | Yes(1), Optical Yes(1) |
Input - USB | USB3.0 Type A(3)USB2.0 Type A(3) |
Input - RJ45(LAN) | Yes(1) |
Input - RS232C IN | Yes(1) |
Input - Audio In | Yes(1) |
Input - Analog - RGB | Yes(1) |
Input - Digital - HDMI | Yes(3), HDCP2.2/1.4 |
Panel | |
Portrait / Landscape | No / Yes |
Operation Hours (Hours/Day) | 16/7 |
Life Time | 30,000 Hrs (Min.) |
Surface Treatment(Haze) | Anti Glare, 7H(Mohs) |
Response Time | 8ms (G to G) |
Colour Depth | 10bit, 1.07Billon colours |
Viewing Angle(H x V) | 178 x 178 |
Colour Gamut | NTSC 68% |
Contrast Ratio | 1,200:1 |
Brightness | 490nit (wo Glass max),390nit (wo Glass typ), 335nit (wo Glass, min)450nit (w Glass, max),350nit (w Glass, typ), 300nit (w Glass min) |
Refresh Rate | 60Hz |
Native Resolution | 3840x2160 (UHD) |
Aspect Ratio | 16:9 |
Back Light Type | Direct |
Panel Technology | IPS |
Screen Size | 65" |
Android System | |
GPU | Dual Core Mail G51 |
SoC | Dual core A73+Dual core A53 |
Special Feature | |
Touch - Multi touch point | Max 20 Points |
Touch - Operating System Support | Windows 7/8/10/WindowsXP/Linux/Mac/Android(WindowsXP/Linux/Mac Support one point touch) |
Touch - Protection Glass Transmission | 87% |
Touch - Protection Glass Thickness | 4T (Anti-Glare) |
Touch - Interface | USB2.0 |
Touch - Accuracy | ±2mm |
Touch - Reponse Time(PC Win10) | 60ms |
Touch - Available object size for touch | Ø3 mm ↑ . |
Accessory | |
Basic | Power Cord 3m, USB Cable (Type A-Type B) 5m, HDMI Cable 3m, Writing Pen (2pcs), User Manual, Quick Start Guide, Carton Box, Remote Controller(include battery 2ea), WiFi module |
LANGUAGE | |
OSD | OSD - English, Simplified Chineses, Catalan, Czech, Denmark, Arabic(Egypt), Finnish, French, German, Greek, Italian, Japanese, Korean, Netherlands(Dutch), Norwegian, Polski, Portugues(Europe),Portugues(Brazil) Romanian, Russian, Spanish, Swedish, Turkish, Ukrainian, Traditional Chinese |
OPS COMPATIBILITY | |
OPS Power Built In | Yes |
OPS Type Compatible | Yes (Slot) |
CERTIFICATION | |
ErP / Energy Star | Yes / No |
EMC | FCC Class "A" / CE |
Safety | CB / NRTL |
Sound | |
Speaker | Yes (10W x 2) |
Power Consumption | |
Power off | 0.5W |
BTU (British Thermal Unit) | TBD |
Max. | 300 W |
Typ. | 180W |
POWER | |
Power Type | Built-In Power |
Power Supply | AC 100-240V~, 50/60Hz |
Environment Conditions | |
Operation Humidity | 10% to 80% |
Operation Temperature | 0 °C to 40 °C |
KEY FEATURE | |
SW - HDMI-CEC | Yes (Debug Mode) |
SW - Screen Share | Yes (Screenshare pro) |
SW - webOS ver. | Android 8.0 |
HW - Local Key Operation | Yes |
HW - Power Indicator | Yes |
HW - Wi-Fi - Built-in | Yes (Slot type) |
HW - Internal Memory | 32GB |
Mechanical Specification | |
VESA™ Standard Mount Interface | 600x400 |
Handle | Yes |
Carton Dimensions(W x H x D) (Box outer size) | 1628 |
